Single row open tapered roller bearing NTN 4T-L44649/L44610 for cylindrical shafts. Steel cage, inch size series.
The maximum rotation speed is 7400 rpm. The calculated dynamic load is 28.8 kN, the calculated static load is 34 kN. Manufacturer's recommended operating temperature is from -40 °C to 120 °C
Outer ring width (C): 10.668 mm.
Inner ring width (B): 14.732 mm.
Total width of the bearing assembly (T): 14.224 mm.
Capable of supporting axial and radial loads like an angular contact bearing. The split design of tapered roller bearings allows the inner ring with rollers and cage to be installed separately from the outer (outer) ring. Often installed in pairs in a back-to-back pattern. or mirrored.
Found under catalog numbers: L44649/10, L44649R/10, etc.
