  • 6209HT200ZZ SNR Bearing (45х85х19 mm.)
  • 6209HT200ZZ SNR Bearing (45х85х19 mm.)
  • 6209HT200ZZ SNR Bearing (45х85х19 mm.)
Features
Brand SNR
Designation 6209HT200ZZ
Dimensions [d x D x W] 45х85х19 mm.
Bore diameter (d) 1.772 in. / 45 mm.
Outside diameter (D) 3.346 in. / 85 mm.
Width (B) 0.748 in. / 19 mm.
Weight 0.1814 lbs. / 0.4 kg.
Sealing Shield on both sides
Bearing Material Bearing steel
Cage Sheet metal
Radial internal clearance Greater than Normal
Tolerance class Normal
Number of rows 1
Outer ring type Cylindrical
Bore type Cylindrical
Series Metric
Description

Single row sealed high-temperature deep groove ball bearing SNR 6209HT200ZZ series TOPLINE for use at high temperatures up to +200°C.

The maximum rotation speed is 4600 rpm. Design dynamic load 32.2 kN, design static load 20.4 kN.

Does not require re-lubrication throughout its service life.
