  • 6204ZC3 SNR Bearing (20х47х14 mm.)
  • 6204ZC3 SNR Bearing (20х47х14 mm.)
  • 6204ZC3 SNR Bearing (20х47х14 mm.)
Features
Brand SNR
Designation 6204ZC3
Dimensions [d x D x W] 20х47х14 mm.
Bore diameter (d) 0.787 in. / 20 mm.
Outside diameter (D) 1.85 in. / 47 mm.
Width (B) 0.551 in. / 14 mm.
Weight 0.0485 lbs. / 0.107 kg.
Sealing Shield on one side
Bearing Material Bearing steel
Cage Sheet metal
Radial internal clearance Greater than Normal (C3)
Tolerance class Normal
Number of rows 1
Outer ring type Cylindrical
Bore type Cylindrical
Series Metric
Description

Single row semi-closed deep groove ball bearing SNR 6204ZC3.

Limit rotation speed 14000 rpm. Design dynamic load 12.8 kN, design static load 6.6 kN.
Increased internal radial clearance C3, may be designated 6204ZJ30
