  • 6014ZZC3 SNR Bearing (70х110х20 mm.)
  • 6014ZZC3 SNR Bearing (70х110х20 mm.)
  • 6014ZZC3 SNR Bearing (70х110х20 mm.)
Features
Brand SNR
Designation 6014ZZC3
Dimensions [d x D x W] 70х110х20 mm.
Bore diameter (d) 2.756 in. / 70 mm.
Outside diameter (D) 4.331 in. / 110 mm.
Width (B) 0.787 in. / 20 mm.
Weight 0.2767 lbs. / 0.61 kg.
Sealing Shield on both sides
Bearing Material Bearing steel
Cage Sheet metal
Radial internal clearance Greater than Normal (C3)
Tolerance class Normal
Number of rows 1
Outer ring type Cylindrical
Bore type Cylindrical
Series Metric
Description

Single row sealed deep groove ball bearing SNR 6014ZZC3.

Limit rotation speed 5500 rpm. Design dynamic load 36 kN, design static load 28.5 kN.

Does not require re-lubrication throughout its service life.
Increased internal radial clearance C3, can be designated 6014ZZJ30

A new review or comment
Sign in with
Rate this item
Share

6014ZZC3 SNR Bearing (70х110х20 mm.)

Out of stock
SKU: 6014ZZC3SNR70X110X20!#_
Price upon request
