  • 24140EMW33 SNR Bearing (200х340х140 mm.)
  • 24140EMW33 SNR Bearing (200х340х140 mm.)
  • 24140EMW33 SNR Bearing (200х340х140 mm.)
Features
Brand SNR
Designation 24140EMW33
Dimensions [d x D x W] 200х340х140 mm.
Bore diameter (d) 7.874 in. / 200 mm.
Outside diameter (D) 13.386 in. / 340 mm.
Width (B) 5.512 in. / 140 mm.
Weight 23.2693 lbs. / 51.3 kg.
Sealing Without / Open
Radial internal clearance Normal
Tolerance class Normal
Bearing Material Bearing steel
Cage Machined brass
Number of rows 2
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Double-row open spherical roller bearing SNR 24140EMW33 for cylindrical shafts. Solid brass cage, holes and lubrication groove on outer (outer) ring.

The maximum rotation speed is 1500 rpm. Design dynamic load 2130 kN, design static load 2930 kN.
Able to withstand significant radial loads and, due to its internal design, withstand axial distortions and misalignments. Well suited for use in harsh conditions (vibration, shock, crushers, vibrating screens, etc.).
