  • 23226EMW33C3 SNR Bearing (130х230х80 mm.)
  • 23226EMW33C3 SNR Bearing (130х230х80 mm.)
  • 23226EMW33C3 SNR Bearing (130х230х80 mm.)
Features
Brand SNR
Designation 23226EMW33C3
Dimensions [d x D x W] 130х230х80 mm.
Bore diameter (d) 5.118 in. / 130 mm.
Outside diameter (D) 9.055 in. / 230 mm.
Width (B) 3.15 in. / 80 mm.
Weight 6.246 lbs. / 13.77 kg.
Sealing Without / Open
Radial internal clearance Greater than Normal (C3)
Tolerance class Normal
Bearing Material Bearing steel
Cage Machined brass
Number of rows 2
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Double-row open spherical roller bearing SNR 23226EMW33C3 for cylindrical shafts. Solid brass cage, holes and lubrication groove on outer (outer) ring.

The maximum rotation speed is 2600 rpm. Design dynamic load 958 kN, design static load 1130 kN.
Able to withstand significant radial loads and, due to its internal design, withstand axial distortions and misalignments. Well suited for use in harsh conditions (vibration, shock, crushers, vibrating screens, etc.).
