  • 23128EAW33C3 SNR Bearing (140х225х68 mm.)
  • 23128EAW33C3 SNR Bearing (140х225х68 mm.)
  • 23128EAW33C3 SNR Bearing (140х225х68 mm.)
Features
Brand SNR
Designation 23128EAW33C3
Dimensions [d x D x W] 140х225х68 mm.
Bore diameter (d) 5.512 in. / 140 mm.
Outside diameter (D) 8.858 in. / 225 mm.
Width (B) 2.677 in. / 68 mm.
Weight 4.9442 lbs. / 10.9 kg.
Sealing Without / Open
Radial internal clearance Greater than Normal (C3)
Tolerance class Normal
Bearing Material Bearing steel
Cage Sheet metal
Number of rows 2
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Double-row open spherical roller bearing SNR 23128EAW33C3 for cylindrical shafts. Steel cage, holes and lubrication groove on outer (outer) ring.

The maximum rotation speed is 2800 rpm. Design dynamic load 802 kN, design static load 1030 kN.
Able to withstand significant radial loads and, due to its internal design, withstand axial distortions and misalignments. Well suited for use in harsh conditions (vibration, shock, crushers, vibrating screens, etc.).

A new review or comment
Sign in with
Rate this item
Share

23128EAW33C3 SNR Bearing (140х225х68 mm.)

Out of stock
SKU: 23128EAW33C3SNR140X225X68!#_
Price upon request
