  • 23034EAW33C2 SNR Bearing (170х260х67 mm.)
  • 23034EAW33C2 SNR Bearing (170х260х67 mm.)
  • 23034EAW33C2 SNR Bearing (170х260х67 mm.)
Features
Brand SNR
Designation 23034EAW33C2
Dimensions [d x D x W] 170х260х67 mm.
Bore diameter (d) 6.693 in. / 170 mm.
Outside diameter (D) 10.236 in. / 260 mm.
Width (B) 2.638 in. / 67 mm.
Weight 5.8967 lbs. / 13 kg.
Sealing Without / Open
Radial internal clearance Smaller than Normal (C2)
Tolerance class Normal
Bearing Material Bearing steel
Cage Sheet metal
Number of rows 2
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Double-row open spherical roller bearing SNR 23034EAW33C2 for cylindrical shafts. Steel cage, holes and lubrication groove on outer (outer) ring.

The maximum rotation speed is 2700 rpm. Design dynamic load 914 kN, design static load 1240 kN.
Able to withstand significant radial loads and, due to its internal design, withstand axial distortions and misalignments. Well suited for use in harsh conditions (vibration, shock, crushers, vibrating screens, etc.).

A new review or comment
Sign in with
Rate this item
Share

23034EAW33C2 SNR Bearing (170х260х67 mm.)

Out of stock
SKU: 23034EAW33C2SNR170X260X67!#_
Price upon request
