  • 22226EMW33C3 SNR Bearing (130х230х64 mm.)
  • 22226EMW33C3 SNR Bearing (130х230х64 mm.)
  • 22226EMW33C3 SNR Bearing (130х230х64 mm.)
Features
Brand SNR
Designation 22226EMW33C3
Dimensions [d x D x W] 130х230х64 mm.
Bore diameter (d) 5.118 in. / 130 mm.
Outside diameter (D) 9.055 in. / 230 mm.
Width (B) 2.52 in. / 64 mm.
Weight 4.9442 lbs. / 10.9 kg.
Sealing Without / Open
Radial internal clearance Greater than Normal (C3)
Tolerance class Normal
Bearing Material Bearing steel
Cage Machined brass
Number of rows 2
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Double-row open spherical roller bearing SNR 22226EMW33C3 for cylindrical shafts. Solid brass cage, holes and lubrication groove on outer (outer) ring.

The maximum rotation speed is 3600 rpm. Design dynamic load 808 kN, design static load 898 kN.
Able to withstand significant radial loads and, due to its internal design, withstand axial distortions and misalignments. Well suited for use in harsh conditions (vibration, shock, crushers, vibrating screens, etc.).

A new review or comment
Sign in with
Rate this item
Share

22226EMW33C3 SNR Bearing (130х230х64 mm.)

Out of stock
SKU: 22226EMW33C3SNR130X230X64!#_
Price upon request
