  • 10X22206EAW33EE SNR Bearing (30х62х25 mm.)
  • 10X22206EAW33EE SNR Bearing (30х62х25 mm.)
  • 10X22206EAW33EE SNR Bearing (30х62х25 mm.)
Features
Brand SNR
Designation 10X22206EAW33EE
Dimensions [d x D x W] 30х62х25 mm.
Bore diameter (d) 1.181 in. / 30 mm.
Outside diameter (D) 2.441 in. / 62 mm.
Width (B) 0.984 in. / 25 mm.
Weight 0.1497 lbs. / 0.33 kg.
Sealing Seal on both sides
Radial internal clearance Normal
Tolerance class Normal
Bearing Material Bearing steel
Cage Sheet metal
Number of rows 2
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Double-row closed spherical roller bearing SNR 10X22206EAW33EE for cylindrical shafts. Steel cage, holes and lubrication groove on outer (outer) ring.

The maximum rotation speed is 3100 rpm. Design dynamic load 75.7 kN, design static load 64.5 kN.
Able to withstand significant radial loads and, due to its internal design, withstand axial distortions and misalignments. Well suited for use in harsh conditions (vibration, shock, crushers, vibrating screens, etc.).
