  • RNA2203XLL/3AS NTN Bearing (22х40х15.8 mm.)
  • RNA2203XLL/3AS NTN Bearing (22х40х15.8 mm.)
Features
Bore diameter (d) 0.866 in. / 22 mm.
Outside diameter (D) 1.575 in. / 40 mm.
Width (B) 0.622 in. / 15.8 mm.
OR Width (C) 0.622 in. / 15.8 mm.
Series Metric
Dimensions [d x D x W] 22х40х15.8 mm.
Weight 0.0472 lbs. / 0.104 kg.
Number of rows 1
Sealing Seal on both sides
Radial internal clearance Greater than Normal
Tolerance class Normal
Bore type Cylindrical
Outer ring type Spherical
Bearing Material Bearing steel
Cage Sheet metal
Description

Single-row closed support roller (roller) with a cylindrical surface of the outer (outer) ring NTN RNA2203XLL/3AS for cylindrical shafts.
Roller dimensions 22*40*15.8 mm.
The roller is made on the basis of a needle roller bearing without an inner ring, with contact seals on both sides. Thick-walled outer ring with a cylindrical running surface for use with all types of tracks, for use in conveyor systems and cam drives.

Rated dynamic load 10.4 kN, rated static load 15.6 kN.
Width outer ring: 15.8 mm.
The design of the roller allows the inner ring to be installed separately from the outer ring with the rolling elements.
