  • RNA2201XLL/3AS NTN Bearing (16х32х13.8 mm.)
  • RNA2201XLL/3AS NTN Bearing (16х32х13.8 mm.)
Features
Bore diameter (d) 0.63 in. / 16 mm.
Outside diameter (D) 1.26 in. / 32 mm.
Width (B) 0.543 in. / 13.8 mm.
OR Width (C) 0.543 in. / 13.8 mm.
Series Metric
Dimensions [d x D x W] 16х32х13.8 mm.
Weight 0.0259 lbs. / 0.057 kg.
Number of rows 1
Sealing Seal on both sides
Radial internal clearance Greater than Normal
Tolerance class Normal
Bore type Cylindrical
Outer ring type Spherical
Bearing Material Bearing steel
Cage Sheet metal
Description

Single-row closed support roller (roller) with a cylindrical surface of the outer (outer) ring NTN RNA2201XLL/3AS for cylindrical shafts.
Roller dimensions 16*32*13.8 mm.
The roller is made on the basis of a needle roller bearing without an inner ring, with contact seals on both sides. Thick wall outer ring with cylindrical running surface for use with all types of tracks, conveyor systems and cam drives.

Rated dynamic load 8.1 kN, rated static load 10.3 kN.
Width outer ring: 13.8 mm.
The design of the roller allows the inner ring to be installed separately from the outer ring with the rolling elements.
