  • RNA22/6XLL/3AS NTN Bearing (10х19х11.8 mm.)
  • RNA22/6XLL/3AS NTN Bearing (10х19х11.8 mm.)
Features
Bore diameter (d) 0.394 in. / 10 mm.
Outside diameter (D) 0.748 in. / 19 mm.
Width (B) 0.465 in. / 11.8 mm.
OR Width (C) 0.465 in. / 11.8 mm.
Series Metric
Dimensions [d x D x W] 10х19х11.8 mm.
Weight 0.0091 lbs. / 0.02 kg.
Number of rows 2
Sealing Seal on both sides
Radial internal clearance Greater than Normal
Tolerance class Normal
Bore type Cylindrical
Outer ring type Spherical
Bearing Material Bearing steel
Cage Sheet metal
Description

Double-row closed support roller (roller) with a cylindrical surface of the outer (outer) ring NTN RNA22/6XLL/3AS for cylindrical shafts.
Roller dimensions 10*19*11.8 mm.
The roller is made on the basis of a needle roller bearing without an inner ring, with contact seals on both sides. Thick-walled outer ring with a cylindrical running surface for use with all types of tracks, for use in conveyor systems and cam drives.

Rated dynamic load 4.55 kN, rated static load 4.25 kN.
Width outer ring: 11.8 mm.
The design of the roller allows the inner ring to be installed separately from the outer ring with the rolling elements.
