Features
Brand NTN
Designation NUP2206EG1U
Dimensions [d x D x W] 30х62х20 mm.
Bore diameter (d) 1.181 in. / 30 mm.
Outside diameter (D) 2.441 in. / 62 mm.
Width (B) 0.787 in. / 20 mm.
Weight 0.1338 lbs. / 0.295 kg.
Sealing Without / Open
Radial internal clearance Normal
Tolerance class Normal
Bearing Material Bearing steel
Cage Machined brass
Number of rows 1
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Single-row open radial roller bearing NTN NUP2206EG1U with dimensions 30*62*20 mm.
It has a split design and a massive brass cage. The outer ring has two guide flanges, the inner ring has one flange and one removable flange in the form of a free ring. Designed to withstand one-sided radial load.

Designed dynamic load 49 kN, calculated static load 50 kN. Normal axial clearance.
A roller bearing of this design provides two-way fixation of the shaft, withstands significant axial loads and a relatively high rotation speed. Well suited for use in harsh conditions.
