Single-row open radial roller bearing NTN NU1040C3 with dimensions 200*310*51 mm.
It has a split design and a massive brass cage. The outer ring has two guide flanges, the inner ring has no flanges. Designed to withstand one-sided radial load.
Calculated dynamic load 430 kN, calculated static load 580 kN. Increased axial clearance (C3).
A roller bearing of this design is capable of accepting axial displacement of the shaft relative to the housing in two directions, withstands significant axial loads and a relatively high rotation speed. Well suited for use in harsh conditions.
