Double-row open combined bearing without inner ring NTN NKXR40T2 with dimensions 40*52*32 mm.
This bearing is based on a needle roller bearing and a roller thrust bearing. Simple and robust detachable design, compact dimensions, works well at relatively high speeds, precise positioning of rollers in glass-filled polyamide separator windows. The outer ring has two guide flanges, an annular groove and lubrication holes.

Designed dynamic load 25.9 kN, calculated static load 52.5 kN.
The bearing of this design can withstand significant simultaneous axial and radial loads at relatively high rotation speeds. The axial displacement of the shaft is limited by the width of the inner ring raceway. Can be used with an inner ring, which is sold separately.
