Double-row open combined bearing without inner ring NTN NKX60 with dimensions 60*72*40 mm.
This bearing is based on a needle roller bearing and a thrust ball bearing. Simple and robust split design, compact dimensions, excellent performance at relatively high speeds, precise positioning of rollers in pressed steel separator windows. The outer ring has two guide flanges, an annular groove and lubrication holes.

Designed dynamic load 29.8 kN, calculated static load 71.5 kN. Normal axial clearance.
The bearing of this design can withstand significant simultaneous axial and radial loads at relatively high rotation speeds. The axial displacement of the shaft is limited by the width of the inner ring raceway. Can be used with an inner ring, which is sold separately.
