  • AXK1101 NTN Bearing (12х26х2 mm.)
  • AXK1101 NTN Bearing (12х26х2 mm.)
  • AXK1101 NTN Bearing (12х26х2 mm.)
Features
Brand NTN
Designation AXK1101
Dimensions [d x D x W] 12х26х2 mm.
Bore diameter (d) 0.472 in. / 12 mm.
Outside diameter (D) 1.024 in. / 26 mm.
Width (B) 0.079 in. / 2 mm.
Weight 0.0009 lbs. / 0.002 kg.
Sealing Without / Open
Radial internal clearance Normal
Tolerance class Normal
Bearing Material Bearing steel
Cage Sheet metal
Number of rows 1
Series Metric
Description

Rolling bodies with cage NTN AXK1101 internal part of a single-row roller (needle) support bearing. Used with support rings (washers) of the support roller/needle bearing, which are selected and supplied separately.

Rated dynamic load 9.85 kN, calculated static load 28.9 kN.

Is integral part of a thrust roller (needle) bearing. The rolling elements are made of special bearing steel, in accordance with the technological requirements for the manufacture of bearings.
Can be found with the designation AXK 1226, etc.

A new review or comment
Sign in with
Rate this item
Share

AXK1101 NTN Bearing (12х26х2 mm.)

Out of stock
SKU: AXK1101NTN12X26X2!#_
Price upon request
