  • 5215S NTN Bearing (75х130х41.3 mm.)
  • 5215S NTN Bearing (75х130х41.3 mm.)
  • 5215S NTN Bearing (75х130х41.3 mm.)
Features
Brand NTN
Designation 5215S
Dimensions [d x D x W] 75х130х41.3 mm.
Bore diameter (d) 2.953 in. / 75 mm.
Outside diameter (D) 5.118 in. / 130 mm.
Width (B) 1.626 in. / 41.3 mm.
Weight 0.8618 lbs. / 1.9 kg.
Sealing Without / Open
Number of rows 2
Radial internal clearance Normal
Tolerance class Normal
Bore type Cylindrical
Outer ring type Cylindrical
Bearing Material Bearing steel
Cage Polymer
Series Metric
Description

Double-row open angular contact ball bearing NTN 5215S for cylindrical shafts.

Limit rotation speed 3200 rpm. Design dynamic load 93.5 kN, design static load 83 kN. Contact angle α = 25 °
Slight differences in contact angle allow replacement of 3215 bearings from other manufacturers.
