Single row open tapered roller bearing NTN 4T-LM29749/LM29711 for cylindrical shafts. Steel cage, inch size series.
Rated dynamic load 43.5 kN, rated static load 57 kN.
Outer ring width (B): 15.748 mm.
Width inner ring (C): 19.812 mm.
Total width of bearing assembly (T): 19.812 mm.
Capable of supporting axial and radial loads like an angular contact bearing. The split design of tapered roller bearings allows the inner ring with rollers and cage to be installed separately from the outer (outer) ring. Often installed in pairs in a back-to-back or mirrored pattern.
