Single row open tapered roller bearing NTN 4T-33207 for cylindrical shafts. Steel cage, metric size series.
Limit rotation speed 5500 rpm. Design dynamic load 109 kN, design static load 0.539 kN. Manufacturer's recommended operating temperature -40°C to 120°C
Outer ring width (B): 22 mm.
Inner ring width (C): 28 mm.
Overall width bearing assembly (T): 28 mm.
ISO 355 designation: T2DE035
Capable of supporting axial and radial loads as an angular contact bearing. The split design of tapered roller bearings allows the inner ring with rollers and cage to be installed separately from the outer (outer) ring. Often installed in pairs in a back-to-back pattern or mirrored.
Found under catalog numbers: 215776, etc.
