Single row open tapered roller bearing NTN 4T-30207 for cylindrical shafts. Steel cage, metric size series.
Limit rotation speed 5500 rpm. Design dynamic load 61.5 kN, design static load 0.341 kN. Manufacturer's recommended temperature of use is from -40 °C to 120 °C
Outer ring width (B): 15 mm.
Inner ring width (C): 17 mm.
Overall bearing assembly width (T): 18.25 mm.
ISO 355 designation: T3DB035
Capable of supporting axial and radial loads like an angular contact bearing. The split design of tapered roller bearings allows the inner ring with rollers and cage to be installed separately from the outer (outer) ring. Often installed in pairs in a back-to-back pattern. or mirrored.
Found under catalog numbers: 235987, 13647, etc.
