Single row open tapered roller bearing NTN 4T-2687/2631 for cylindrical shafts. Steel cage, inch size series.

Limit rotation speed 6200 rpm. Design dynamic load 72.5 kN, design static load 0.444 kN. Manufacturer's recommended operating temperature -40°C to 120°C

Outer ring width (B): 19.05 mm.
Inner ring width (C): 25.433 mm.
Total width of bearing assembly (T): 23.812 mm.
Capable of supporting axial and radial loads like an angular contact bearing. The split design of tapered roller bearings allows the inner ring with rollers and cage to be installed separately from the outer (outer) ring. Often installed in pairs in a back-to-back or mirrored pattern.
