Single row open tapered roller bearing NTN 32015XU for cylindrical shafts. Steel cage, metric size series.
Limit rotation speed 3000 rpm. Design dynamic load 167 kN, design static load 0.912 kN. Manufacturer's recommended operating temperature -40°C to 120°C
Outer ring width (B): 19 mm.
Inner ring width (C): 25 mm.
Overall width bearing assembly (T): 25 mm.
ISO 355 designation: T4CC075
Capable of supporting axial and radial loads as an angular contact bearing. The split design of tapered roller bearings allows the inner ring with rollers and cage to be installed separately from the outer (outer) ring. Often installed in pairs in a back-to-back pattern or mirrored.
Found under catalog numbers: AZ43476+Z55493, AL156503+L154621, etc.
