  • 2314SC3 NTN Bearing (70х150х51 mm.)
  • 2314SC3 NTN Bearing (70х150х51 mm.)
  • 2314SC3 NTN Bearing (70х150х51 mm.)
Features
Brand NTN
Designation 2314SC3
Number of rows 2
Dimensions [d x D x W] 70х150х51 mm.
Bore diameter (d) 2.756 in. / 70 mm.
Outside diameter (D) 5.906 in. / 150 mm.
Width (B) 2.008 in. / 51 mm.
Radial internal clearance Greater than Normal (C3)
Bearing Material Bearing steel
Cage Sheet metal
Sealing Without / Open
Bore type Cylindrical
Outer ring type Cylindrical
Tolerance class Normal
Weight 1.769 lbs. / 3.9 kg.
Description

Double-row open self-aligning (self-aligning) spherical deep groove ball bearing NTN 2314SC3 with a stamped steel cage for cylindrical shafts.

The maximum rotation speed is 3600 rpm. Design dynamic load 111 kN, design static load 37.5 kN.
Able to compensate for angular misalignments of the shaft due to the common spherical raceway of the outer ring. Self-centering due to internal design.
