  • 23128EAW33 NTN Bearing (130х210х64 mm.)
  • 23128EAW33 NTN Bearing (130х210х64 mm.)
  • 23128EAW33 NTN Bearing (130х210х64 mm.)
Features
Brand NTN
Designation 23128EAW33
Dimensions [d x D x W] 130х210х64 mm.
Bore diameter (d) 5.118 in. / 130 mm.
Outside diameter (D) 8.268 in. / 210 mm.
Width (B) 2.52 in. / 64 mm.
Weight 4.8172 lbs. / 10.62 kg.
Sealing Without / Open
Radial internal clearance Normal
Tolerance class Normal
Bearing Material Bearing steel
Cage Sheet metal
Number of rows 2
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Double row open spherical roller bearing NTN 23128EAW33 for cylindrical shafts, with holes and lubrication groove on the outer ring, cylindrical outer surface. Steel separator. Bearing dimensions: 130*210*64 mm.
Normal radial clearance.

The maximum rotation speed is 2800 rpm. Design dynamic load 802 kN, design static load 1030 kN.
Able to withstand significant radial loads and, due to its internal design, withstand axial distortions and misalignments. Well suited for use in harsh conditions (vibration, shock, crushers, vibrating screens, etc.).
