Features
Brand SNR
Designation N340EMJ30
Dimensions [d x D x W] 200х420х80 mm.
Bore diameter (d) 7.874 in. / 200 mm.
Outside diameter (D) 16.535 in. / 420 mm.
Width (B) 3.15 in. / 80 mm.
Weight 25.8548 lbs. / 57 kg.
Sealing Without / Open
Radial internal clearance Greater than Normal (C3)
Tolerance class Normal
Bearing Material Bearing steel
Cage Machined brass
Number of rows 1
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Single-row open radial roller bearing SNR N340EMJ30 with dimensions 200*420*80 mm.
Has a split design and a brass cage. The inner ring has two guide flanges, the outer ring has no flanges. Designed to withstand one-sided radial load.

The maximum rotation speed is 2400 rpm. Design dynamic load 1220 kN, design static load 1590 kN. Increased axial clearance (C3/J30).
A roller bearing of this design is capable of accepting axial displacement of the shaft relative to the housing in two directions, withstands significant axial loads and a relatively high rotation speed. Well suited for use in harsh conditions.
