  • 23134EAW33 SNR Bearing (170х280х88 mm.)
  • 23134EAW33 SNR Bearing (170х280х88 mm.)
  • 23134EAW33 SNR Bearing (170х280х88 mm.)
Features
Brand SNR
Designation 23134EAW33
Dimensions [d x D x W] 170х280х88 mm.
Bore diameter (d) 6.693 in. / 170 mm.
Outside diameter (D) 11.024 in. / 280 mm.
Width (B) 3.465 in. / 88 mm.
Weight 9.7749 lbs. / 21.55 kg.
Sealing Without / Open
Radial internal clearance Normal
Tolerance class Normal
Bearing Material Bearing steel
Cage Sheet metal
Number of rows 2
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Double-row open spherical roller bearing SNR 23134EAW33 for cylindrical shafts. Steel cage, holes and lubrication groove on outer (outer) ring.

The maximum rotation speed is 2300 rpm. Design dynamic load 1270 kN, design static load 1700 kN.
Able to withstand significant radial loads and, due to its internal design, withstand axial distortions and misalignments. Well suited for use in harsh conditions (vibration, shock, crushers, vibrating screens, etc.).
