Features
Brand NTN
Designation NJ2306EG1
Dimensions [d x D x W] 30х72х27 mm.
Bore diameter (d) 1.181 in. / 30 mm.
Outside diameter (D) 2.835 in. / 72 mm.
Width (B) 1.063 in. / 27 mm.
Weight 0.2595 lbs. / 0.572 kg.
Sealing Without / Open
Radial internal clearance Normal
Tolerance class Normal
Bearing Material Bearing steel
Cage Machined brass
Number of rows 1
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Single-row open radial roller bearing NTN NJ2306EG1 with dimensions 30*72*27 mm.
Has a split design and a massive brass cage. The outer ring has two guide flanges, the inner ring has one flange. Designed to withstand one-sided radial load.

Designed dynamic load 74.5 kN, calculated static load 77.5 kN. Normal axial clearance.
A roller bearing of this design provides one-way fixation of the shaft, can accommodate axial displacement of the shaft relative to the housing in only one direction, and can withstand significant axial loads and relatively high rotation speeds. Well suited for use in harsh conditions.

A new review or comment
Sign in with
Rate this item
Share

NJ2306EG1 NTN Bearing (30х72х27 mm.)

Out of stock
SKU: NJ2306EG1NTN30X72X27!#_
Price upon request
