Features
Brand NTN
Designation NJ206EG1C3
Dimensions [d x D x W] 30х62х16 mm.
Bore diameter (d) 1.181 in. / 30 mm.
Outside diameter (D) 2.441 in. / 62 mm.
Width (B) 0.63 in. / 16 mm.
Weight 0.1043 lbs. / 0.23 kg.
Sealing Without / Open
Radial internal clearance Greater than Normal (C3)
Tolerance class Normal
Bearing Material Bearing steel
Cage Machined brass
Number of rows 1
Series Metric
Bore type Cylindrical
Outer ring type Cylindrical
Description

Single-row open radial roller bearing NTN NJ206EG1C3 with dimensions 30*62*16 mm.
It has a split design and a massive brass cage. The outer ring has two guide flanges, the inner ring has one flange. Designed to withstand one-sided radial load.

Designed dynamic load 39 kN, calculated static load 37.5 kN. Increased axial clearance (C3).
A roller bearing of this design provides one-way fixation of the shaft, can accommodate axial displacement of the shaft relative to the housing in only one direction, and can withstand significant axial loads and relatively high rotation speeds. Well suited for use in harsh conditions.
